الوصف
- Socket: AMD Socket AM5
- Compatibility: Supports AMD Ryzen™ 7000, Ryzen™ 8000, and Ryzen™ 9000 Series Processors.
Chipset
Memory
- Type: DDR5
- Supported Speeds: 6400(OC), 6200(OC), 6000(OC), 5600(OC), 5200, 4800, 4400 MT/s
- Slots: 2 x DDR5 DIMM sockets
- Maximum Capacity: Up to 128 GB (64 GB per DIMM)
- Memory Architecture: Dual channel
- Compatibility: Supports non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
- Overclocking Profiles: Supports AMD EXPO™ and Intel® XMP memory modules.
Onboard Graphics
- Integrated Graphics Processor:
- DisplayPort: 1 x DisplayPort 1.4, supporting up to 3840×2160@144 Hz
- HDMI: 1 x HDMI 2.1, supporting up to 4096×2160@60 Hz
- Display Support: Supports up to 3 displays simultaneously (Graphics specifications may vary depending on CPU support).
Audio
- Codec: Realtek® Audio CODEC
- Channels: Supports 2/4/5.1/7.1-channel High Definition Audio (7.1-channel audio requires configuration in the audio software).
LAN
- LAN Chip: Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
Expansion Slots
- PCI Express x16 Slot:
- AMD Ryzen™ 7000 Series: Supports PCIe 4.0 x16 mode
- AMD Ryzen™ 8000 Series-Phoenix 1: Supports PCIe 4.0 x8 mode
- AMD Ryzen™ 8000 Series-Phoenix 2: Supports PCIe 4.0 x4 mode
- Note: The PCIEX16 slot can only support a graphics card or an NVMe SSD.
- PCI Express x1 Slot: 1 x PCI Express x1 slot, supporting PCIe 3.0.
Storage Interface
- M.2 Connector:
- Integrated in the CPU
- Supports Socket 3, M key, type 2580 SSDs
- Supported by AMD Ryzen™ 7000 Series: PCIe 4.0 x4/x2 SSDs
- Supported by AMD Ryzen™ 8000 Series-Phoenix 1 & 2: PCIe 4.0 x4/x2 SSDs
- SATA Connectors: 4 x SATA 6Gb/s connectors
- RAID: RAID 0, RAID 1, and RAID 10 support for NVMe SSD and SATA storage devices.
USB Connectivity
- CPU:
- 2 x USB 3.2 Gen 1 ports on the back panel
- 1 x USB 2.0/1.1 port on the back panel
- Chipset:
- 2 x USB 3.2 Gen 1 ports via internal header
- 7 x USB 2.0/1.1 ports (3 on the back panel, 4 via internal headers).
Internal I/O Connectors
- Power Connectors: 1 x 24-pin ATX, 1 x 8-pin ATX 12V
- Cooling: 1 x CPU fan header, 2 x system fan headers
- LED Strip: 1 x addressable LED strip header, 1 x RGB LED strip header
- Storage: 1 x M.2 Socket 3 connector, 4 x SATA 6Gb/s connectors
- Front Panel: 1 x front panel header, 1 x front panel audio header
- USB Headers: 1 x USB 3.2 Gen 1 header, 2 x USB 2.0/1.1 headers
- Additional: 1 x TPM header, 1 x Clear CMOS jumper.
Back Panel Connectors
- USB Ports: 4 x USB 2.0/1.1 ports, 2 x USB 3.2 Gen 1 ports
- Video Outputs: 1 x DisplayPort, 1 x HDMI port
- Networking: 1 x RJ-45 port
- Audio: 3 x audio jacks
- Other: 1 x PS/2 keyboard/mouse port, 1 x Q-Flash Plus button.
I/O Controller
- Chip: iTE® I/O Controller Chip
Hardware Monitoring
- Sensors: Voltage, temperature, fan speed, water cooling flow rate detection
- Warnings: Fan fail warning
- Fan Control: Fan speed control, depending on installed fan.
BIOS
- Flash Memory: 1 x 256 Mbit flash
- BIOS Type: AMI UEFI BIOS
- Supported Standards: PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0.
Unique Features
- Software: Supports GIGABYTE Control Center (GCC)
- BIOS Update: Supports Q-Flash Plus, Q-Flash.
Bundled Software
- Security: Norton® Internet Security (OEM version)
- Networking: LAN bandwidth management software.
Operating System Support
- Windows 11 64-bit
- Windows 10 64-bit
Form Factor
- Type: Micro ATX
- Dimensions: 23.0cm x 22.5cm
This motherboard provides a solid foundation for building a powerful and modern system with AMD’s latest Ryzen processors, offering a balance of performance, expandability, and connectivity.
