| Model name |
24B20JH2 |
| Panel |
23.8″ / IPS |
| Pixel Pitch (mm) |
0.2745 (H) × 0.2745 (V) |
| Effective Viewing Area (mm) |
527.04 (H) × 296.46 (V) |
| Brightness (typical) |
250 cd/m² |
| Contrast Ratio |
1000 : 1 (typical) 20 Million : 1 (DCR) |
| Response Time |
1ms (MPRT) |
| Viewing Angle |
178° (H) / 178° (V) (CR > 10) |
| Color Gamut |
NTSC 90% (CIE1976) / sRGB 100% (CIE1931) |
| Color Accuracy |
– |
| Optimum Resolution |
1920 × 1080 @ 100Hz – HDMI; 1920 × 1080 @ 75Hz – VGA |
| Display Colors |
16.7 Million |
| Signal Input |
VGA × 1, HDMI 1.4 × 1 |
| HDCP Version |
HDMI : 1.4 |
| USB Hub |
– |
| Power Supply |
External 12VDC, 2.5A |
| Power Consumption (typical) |
24W |
| Speakers |
– |
| Line in & Earphone |
– |
| Wall-Mount |
100×100 mm ( 2holes) |
| Adjustable Stand |
Tilt : —5° ~ 15° |
| Product without Stand (mm) |
321.3 (H) × 540.9 (W) × 35.1 (D) |
| Product with Stand (mm) |
418.2 (H) × 540.9 (W) × 168 (D) |
| Packaging (mm) |
387 (H) × 598 (W) × 100 (D) |
| Product without Stand (kg) |
2.49 |
| Product with Stand (kg) |
2.82 |
| Product with Packaging (kg) |
3.92 |
| Cabinet Color |
Black |
| Regulatory Approvals |
CE / RCM / MEPS / BSMI / RoHS |
